Fish Feed Making Machine

The puffed fish feed making machine is an industrial automatic production line that uses various grains or animal products as the main raw materials to produce puffed feed. This production line adopts a twin screw extrusion production process, which utilizes the high temperature, high pressure, and shear force during the extrusion process to cause the starch and animal and plant proteins in the raw materials to undergo ripening and denaturation. Then, the extrusion shape can be adjusted by changing the mold; The extruded product is then screened, dried, sprayed, and cooled to produce a puffed pet feed product. Compared to non puffed feed, this type of product has advantages such as easy chewing, easy digestion, high nutrient absorption rate, and light weight; It is often used in the production of aquatic floating and suspended feed, cat and dog staple food, as well as some high-end poultry and livestock feed. The fish feed making machine is completed from feeding to finished products in one go, with a high degree of automation. The fish feed making machine main material is food grade stainless steel; High level of automation in the production line, stable product quality, continuous production (capable of producing continuously for no less than 72 hours), no waste, and low energy consumption; Support customized design and manufacturing, and fully cooperate with customers' production needs.









Model	M 85 Fish feed making machine	M 100 Fish feed making machine	M 140 Fish feed making machine	Customized Fish feed making machine
Rated power	200kw	300kw	400kw	Provide customized design and production services according to production capacity requirements and product requirements
Actual power	100kw	150kw	200kw
Floor area	150m2	180m2	220m2
Design capacity	400-500kg/h	700-1000kg/h	1200-2000kg/h
Workers	2-3 workers	4-5 workers	4-5 workers
Main materials	Food grade stainless steel
production process	Configure raw materials → Mixing → Extruding → Screening → Drying → Flavoring → Cooling → Product
Raw materials	Cereal powder bone meal and meat meal
Product category	Expanded pet feed; Cat food; Dog food; Aquatic feed; Suckling pig feed, etc
control mode	Control cabinet control, remote centralized control can be customized
after-sale service	Provide on-site guidance on installation and debugging of equipment, and provide basic production technical guidance; One year warranty for the entire line









1. The production line adopts twin screw extruder, Using high hardness screws for a long service life, providing molds of different shapes.

2. The PLC touch screen displays all its parameters and can be used to set and control the machine, including speed and temperature

3. The material used for equipment in contact with food is food grade stainless steel, which is safe and environmentally friendly

4. The equipment can process a variety of raw materials and products, including snacks, fortified rice, pet food, modified starch, etc

5. The production line is mainly powered by electricity, and other energy options such as gas and steam can also be provided.

6. Stable equipment operation, long usage time, and high product quality.





Q: Are you a factory or a trading company?
A: We are a manufacturer, we can customize different models according to customer needs

Q: How can I trust you for the first time business ?

A: Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba trade assurance service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.

Q: Can you provide the detailed formula of the product?
A: Yes, we can provide customers with various product formulas, and we can also tailor the effects that customers want according to
customer needs.

Q: How is your after-sales service?
A: We will provide customers with pre-sale, mid-sale and after-sale service, debug machines for customers, guide operation, repair
and maintenance, and solve various problems.
