Pet Chew Production Line
Your Professional Pet Chew Production Line Supplier
We specialize in producing all kinds of textured soya protein production line products, mainly 1soya protein production line, meat analogue production line, vegetable protein production line, tvp soya chunks machine, modified starch making machines, tvp soya chunks machine, breakfast corn flakes machine, high moisture vegetarian meat machine, soybean chunks making machine, tvp soya chunks machine, etc.Our company's technical engineers have over 20 years of industry experience, can provide customers with perfect solutions. We has mature technical expertise, advanced process equipment, extensive production experience, and a complete service system.
Why Choose Us
Advanced Equipment
We have more than 10,000 square meters of workshop. The company has established a trade department, a technical department, a production department, a quality inspection department, an after-sales service department, and laboratories. We operate with a fully automatic CNC production line, and are committed to providing customers with the best products and services.
Expansive Market Reach
Our products sell well in mainstream markets such as Europe, North America, Japan, South America, Oceania, and Asia. We have established long-term cooperative relationships with customers around the world, , and have garnered widespread acclaim from satisfied customers.
Customized Services
We welcome product customization, and our team is capable of developing new products or providing technical solutions tailored to customer requirements. lf you have any special request, pls send us the details.
24-hour Online Customer Service
Our customer service is available online 24 hours a day. After receiving the service information or feedback from the customer, we will reply and address the feedback in the shortest time. Our customer service team can provide customers with all support on products, customization, after-sales, etc. at any time.
Feature Of Pet Chew Production Line
Strong teech,clean mouth and teeth. It can produce different shapes like twist,double colors,core filling and so on.
The screw material of dog treats machinery is 38CrMoAl which is wear-resisting.
The dog treat making equipment main body material is stainless steel, which is easy to be cleaned.
The Technical Specification Of Pet Chew Production Line
|
Model |
65 twin screw extruder (dry type) |
70 twin screw extruder ( dry type) |
70 twin screw extruder (wet type) |
75 twin screw extruder (dry type) |
95 twin screw extruder(dry type) |
|
The power of main machine |
22kw |
30kw |
37/45 |
55/75 |
90/110 |
|
Drying type |
Gas/electric |
Gas/electric |
Gas/electric/Steam |
Gas/electric/Steam |
Gas/electric/Steam |
|
Production capacity |
120-150kg/h |
150-180kg/h |
350-400kg/h |
600-800kg/h |
1000-1200kg/h |
|
Appearance size |
12000x4000x2200mm |
13500x4000x2200mm |
16500x4000x3200mm |
18500x4000x3200mm |
21000x4000x3200mm |
Raw materials: All kinds of meat raw powder and glue powder are mixed evenly, and the water content is adjusted.
Raw material conveying: Stainless steel conveyor automatically transfer the material to the screw extruder
Extrusion: The extrusion producing belongs to hot extrusion, but the extrusion temperature can be freely controlled, so the organizational structure, expansion degree, and hardness can be freely controlled.
Cooling: As the dog chew pellets are hot extrusion, the temperature after being formed from the extruder is relatively high, and cooling is required to reduce the overall temperature of the inside and outside of the pellets to normal temperature. Guarantee storage and sale.
Cutting and forming: Cut the cooled long rubber chew stick into chew particles with uniform length. The length of the particles can be freely controlled by adjusting the cutting speed.
Conveyor: Convey the chew to the oven,
Multi-layer oven: The oven is mostly electric oven, the temperature is adjusted between 0-200 degrees through the control cabinet, the inside is stainless steel double-layer mesh bag, which reduces the moisture of chew particles, promotes the curing rate, and increases the shelf life.
Cooling conveyor: Cooling to room temperature for easy packaging.
Technical parameters
|
Model |
EXT100 |
TSE75 |
|
Installed Power |
100kw |
200kw |
|
Capacity |
80-120kg/h |
200-300kg/h |
|
Dimension |
27*2.0*2.2m |
30*2.0*2.6m |
Production Process Of Pet Chew Production Line
Blending→Conditioning→Extruding→(Twisting)→Cooling→Cutting→Drying→Packing
Blending
With paste starch and fresh meat as the main raw materials, with edible gum, flavoring agent, animal fat and other raw materials, in the mixer to mix thoroughly, add to the feeder.
Conditioning
The conditioning mixes and heats raw materials, steam or other liquid.
Extruding
The material will through high pressure, high temperature in the barrel, and then be formed by mold at the outlet.
Twisting
When producing multi-color or special-shaped chews, it is necessary to add a special twisting machine to make the product reach the ideal state.
Cooling
The strip chews pass through one or more cooling conveyor belts to reduce the temperature of the product and shape it.
Cutting
The cutting machine cuts the product at a constant speed according to the set length.
Drying
The high-humidity chews are passed through a hot-air cross-circulation dryer to gradually dry the moisture without destroying the original flavor and extend the shelf life.
Packing
Packing gives protection to the chews food and also give easiness to handle and transport to customer's hand.
Packing and Delivery
| Packaging | All dog chews making machinery are packaged according to international standard export package.Inside is covered by plastic film, outside is wooden case. |
| Shipping |
15-35 working days after receiving deposit. |
FAQ
As one of the leading pet chew production line manufacturers and suppliers in China, we warmly welcome you to buy cheap pet chew production line from our factory. All machines are with high quality and competitive price. Contact us for more details.
